Mondraker Crafty Carbon S - Vortex Grey
- Free Domestic Shipping On Orders Over $100
- Low stock - 1 item left
- Backordered, shipping soon
- Add To Cart For Final Price
Carbon S 2026
The Mondraker Crafty Carbon R is a full-carbon front triangle eMTB built around Bosch's Performance Line CX Smart System motor and an integrated 800Wh Powertube battery. With 150mm of rear travel and 160mm up front via Fox Performance suspension, E-Bike Optimized Zero Suspension System, and Mondraker's Forward Geometry, the Crafty Carbon R delivers efficient climbing and capable descending across any terrain.
SRAM Eagle 70 Transmission drivetrain, DB8 4-piston brakes, WTB Sportterra wheels, and an X-Fusion Manic dropper round out a build designed to go further and ride harder -- powered by Bosch's customizable eMTB mode and the Bosch eBike Flow app.
- Stealth Air carbon front triangle -- E-Bike Optimized Zero Suspension System, 150mm rear travel
- Bosch Performance Line CX Smart System -- 85 or 100Nm torque, 600W peak, Turbo / eMTB / Tour+ / Eco / Walk modes
- Bosch Powertube 800Wh integrated battery -- compatible with 250Wh Powermore range extender
- Bosch Kiox 400 top-tube display with wireless Mini Remote
- RockShox ZEB Base fork -- 160mm, Rush RC damper, 38mm stanchions
- Fox Float X Performance rear shock -- 185x55mm, EVOL LV, 2-position lever
- SRAM Eagle 70 Transmission -- 12-speed
- SRAM DB8 4-piston brakes with 200mm Centerline rotors
- WTB Sportterra Tough 30mm inner width rims with Frequency Sport hubs
- Maxxis Assegai EXO+ front / Minion DHR II DoubleDown rear -- fully tubeless ready
- X-Fusion Manic dropper -- 31.6mm
- Flip-chip geometry adjust -- Standard and Low
- Customizable via Bosch eBike Flow app
| Measurement | SM | MD | ML | LG | XL |
|---|---|---|---|---|---|
| Reach (mm) | 445 / 441 | 460 / 456 | 480 / 476 | 500 / 496 | 520 / 516 |
| Stack (mm) | 638 / 641 | 638 / 641 | 647 / 650 | 656 / 659 | 665 / 668 |
| Top Tube (mm) | 581 / 582 | 596 / 597 | 618 / 619 | 640 / 641 | 662 / 663 |
| Seat Tube Length (mm) | 380 | 410 | 435 | 460 | 490 |
| Head Tube Angle (deg) | 64.5 / 64.15 | 64.5 / 64.15 | 64.5 / 64.15 | 64.5 / 64.15 | 64.5 / 64.15 |
| Seat Tube Angle (deg) | 73 / 72.65 | 73 / 72.65 | 73 / 72.65 | 73 / 72.65 | 73 / 72.65 |
| Effective Seat Angle (deg) | 77.95 / 77.6 | 77.95 / 77.6 | 77.95 / 77.6 | 77.95 / 77.6 | 77.95 / 77.6 |
| Chainstay (mm) | 455 / 456 | 455 / 456 | 455 / 456 | 465 / 466 | 465 / 466 |
| Wheelbase (mm) | 1240 / 1241 | 1255 / 1256 | 1280 / 1281 | 1314 / 1315 | 1338 / 1339 |
| Head Tube Length (mm) | 120 | 120 | 130 | 140 | 150 |
| BB Drop (mm) | -25 / -30 | -25 / -30 | -25 / -30 | -25 / -30 | -25 / -30 |
| BB Height (mm) | 350 / 345 | 350 / 345 | 350 / 345 | 350 / 345 | 350 / 345 |
| Fork Offset (mm) | 44 | 44 | 44 | 44 | 44 |
| Dropper Travel (mm) | 125 | 150 | 170 | 190 | 200 |
Standard / Low = flip-chip position in lower/rear shock mount.
