2026 Specialized Turbo Vado 5.0 IGH Step-Through
- Free Domestic Shipping On Orders Over $100
- In stock
- Backordered, shipping soon
- Add To Cart For Final Price
Turbo Vado 5.0 IGH Step-Through
Urban E-Bike · Step-Through · 710Wh · Enviolo IGH · Gates CDX Belt
The Turbo Vado 5.0 IGH Step-Through shares all the performance of the standard Vado 5.0 IGH — same Turbo Full Power 2.2 motor, same 710Wh battery, same Enviolo AutomatiQ and Gates CDX drivetrain — in a low-step frame design that makes mounting and dismounting effortless. Perfect for city riding with stops and starts, or anyone who prefers the convenience of a step-through.
- Turbo Full Power 2.2 Motor: 250W nominal, 90Nm torque — 4x your pedal power.
- 710Wh Integrated Battery: UL certified, lockable, removable, up to 62 miles eco range.
- Step-Through Frame: Easy on/off — ideal for urban riding with frequent stops.
- Enviolo AutomatiQ IGH: Stepless shifting, 380% range, auto-adjusts to your cadence.
- Gates CDX Belt Drive: Clean, quiet, maintenance-free — no oil, no chains.
- Garmin Radar: Integrated rear radar, visual + audible + haptic alerts up to 140m.
- 80mm Suspension: RockShox Recon Silver RL + Cane Creek Thudbuster seatpost.
- Complete Urban Kit: Fenders, LED lights, rack, kickstand — ready to commute.
Same Vado 5.0 IGH performance, but with the step-through frame that makes it accessible for all riders and all types of city riding.
Turbo Full Power 2.2 Motor
250W nominal, 90Nm torque. Amplifies your effort 4x. Up to 28mph. Quiet, smooth, seamless — flat roads to steep hills.
710Wh Integrated Battery
Fully integrated, lockable, removable. UL certified. Turbo System Lock support. Up to 62 miles eco range.
Step-Through E5 Aluminum Frame
Low entry point for easy mounting and dismounting. Same geo-adjusted performance as standard Vado.
Enviolo AutomatiQ IGH
Stepless shifting, 380% gear range. Set your preferred cadence and forget the shifting — it adapts automatically.
Gates Carbon Drive CDX Belt
122-tooth belt, clean and quiet, no oil, no chain stretch. 50T chainring. All-weather commuting.
Complete Urban Kit
DRYTECH fenders (65mm), Lezyne LED headlight (450 lumen), Spanninga taillight w/ auto brake, MIK HD rack (27kg), kickstand.
| S | M | L | XL | |
|---|---|---|---|---|
| Crank Length | 170 | 170 | 170 | 170 |
| Handlebar Width | 680 | 680 | 680 | 680 |
| Stem Length | 60 | 60 | 75 | 75 |
| Saddle Width | 155 | 155 | 155 | 155 |
| Seatpost Length | 375 | 375 | 375 | 375 |
| Stack | 625 | 639 | 652 | 676 |
| Reach | 423 | 444 | 464 | 481 |
| Headtube Length | 135 | 150 | 165 | 190 |
| Headtube Angle | 68° | 68° | 68° | 68° |
| BB Height | 285 | 285 | 285 | 285 |
| BB Drop | 70 | 70 | 70 | 70 |
| Trail | 96 | 96 | 96 | 96 |
| Fork Length (full) | 480 | 480 | 480 | 480 |
| Fork Rake/Offset | 44 | 44 | 44 | 44 |
| Front Center | 699 | 724 | 750 | 777 |
| Chainstay Length | 470 | 470 | 470 | 470 |
| Wheelbase | 1160 | 1186 | 1212 | 1239 |
| Top Tube Length | 585 | 615 | 645 | 675 |
| Bike Standover Height | 735 | 771 | 771 | 805 |
| Seat Tube Length | 400 | 450 | 460 | 500 |
| Seat Tube Angle | 75.5° | 75° | 74.5° | 74° |
E-Bike
Motor
Specialized 2.2, 250W nominal, 90Nm torque, custom tuned
Battery
Specialized integrated battery, 710Wh, UL certified, lockable, removable, state of charge display
Charger
Custom charger, 42V4A w/ Rosenberger plug, 100-240V
UI/Remote
MasterMind TCD w/ handlebar remote, built-in anti-theft feature, Bluetooth, customizable display pages
Frameset
Frame
E5 Aluminum step-through, bottom bracket motor mount, fully integrated & lockable downtube battery, internal cable routing, lock and front rack mount, sliding dropout
Seat Binder
Specialized Alloy 34.9mm, Steel Bolt
Suspension
Fork
RockShox Recon Silver RL, 80mm travel, Motion-Control
Seatpost
Cane Creek Thudbuster St, suspended, 30.9mm
Brakes
Front Brake
Shimano CUES BL-U8000, 4-piston hydraulic disc
Rear Brake
Shimano CUES BL-U8000, 4-piston hydraulic disc
Drivetrain
Rear Hub
Enviolo Heavy Duty, 380% range, 6-bolt, 10x135mm
Cassette
Gates 22T
Chain/Belt
Gates Carbon Drive CDX 122t belt
Chainring
Gates Carbon Drive CDX 50T
Crankset
Custom alloy forged crankarms
Chain Cover
Specialized Belt Cover
Wheels & Tires
Wheels
29" front / 27.5" rear, 30mm inner width, 32h. Specialized alloy hubs, 6-bolt disc.
Front Tire
Pathfinder Sport Reflect, 650b x 2.3"
Rear Tire
Pathfinder Sport Reflect, 650b x 2.3"
Inner Tubes
Standard 40mm Schrader valve, 650Bx1.75-2.4
Cockpit
Handlebars
Specialized alloy, 15° backsweep, 46mm rise, 31.8mm clamp, 680mm width
Stem
Specialized Flowset, 3D-forged alloy, 20° rise, 31.8mm clamp. S-M: 60mm, L-XL: 75mm
Saddle
Bridge Sport, steel rails, 155mm
Grips
Ergon GA30-S Custom, 134.8mm length
Safety & Security
Turbo System Lock
Disable motor + motion sensor alarm via Specialized app. Motor cannot be re-enabled except by owner.
Radar
Integrated Garmin Radar, visual + audible + haptic alerts on MasterMind TCD, up to 140m range
Headlight
Lezyne Ebike Power STVZO E450+, 450 lumen, 160cm wire, w/ reflector
Taillight
Spanninga STVZO Commuter Glow with auto brake function
Accessories
Fenders
Specialized DRYTECH fenders, 65mm width, extra strong aluminum fenderstay
Rack
Specialized rack, MIK HD interface, built-in pannier mounts, 27kg max load, child seat compatible, thru-axle trailer rated
Kickstand
Specialized kickstand, 40mm mount
Pedals
Specialized Commuter w/ grip tape & reflectors
SWAT
Enviolo threaded freewheel lockring
Weight
Weight
27.1kg (59 lb, 11.9 oz)
Weight Size
MD
