2026 Specialized Crux DSW Comp - SRAM Apex XPLR

$2,800.00
/
Shipping calculated at checkout.
Color
Size
  • Free Domestic Shipping On Orders Over $100
  • Low stock - 5 items left
  • Backordered, shipping soon
  • Add To Cart For Final Price
Crux DSW Comp — SRAM Apex XPLR
Crux DSW Comp
SRAM Apex XPLR · E5 Premium Aluminum · DSW · 9.37kg

The Crux DSW is more than the lightest alloy gravel bike ever made. We took everything we learned creating the carbon Crux and used our patented D'Aluisio Smartweld to make it a reality in alloy. We've created the most capable, nimble, balanced, and responsive alloy gravel bike ever made for fast, fun, high-performance riding. And yeah, it's the lightest too.

  • E5 Premium Aluminum + DSW: 1399g frame (56cm unpainted), hydroformed tubing, patented DSW welds.
  • S-Works FACT Carbon Fork: 12x100mm thru-axle, flat-mount disc.
  • SRAM Apex XPLR: 12-speed mechanical, 40T / 11-44t gravel gearing.
  • 47c / 650b x 2.1" Tire Clearance: Same as carbon Crux — go anywhere at full gas.
  • UDH Dropout: Universal Derailleur Hanger, future-proof.
  • DT Swiss G540 Wheels: Tubeless-ready alloy clinchers, 24mm internal width.
  • Pathfinder Pro 2BR 700x38c: 2Bliss Ready, hooks up over nasty terrain.
  • Performance Gravel Geometry: 72mm BB drop, race-inspired fit, 'cross heritage.

Complete build at 9.37kg (56cm). Six sizes: 49, 52, 54, 56, 58, 61.

E5 Premium Aluminum Frame — DSW Technology
1399g frame (56cm raw, unpainted). Hydroformed aluminum tubing with D'Aluisio Smartweld — single-piece downtube and bottom bracket for better, stronger welds. Threaded BB, tapered head tube, UDH dropout.
D'Aluisio Smartweld (DSW)
Patented engineering process using hydroforming to precisely match tube-to-tube joints. Creates a lighter frame that can be twice as durable as traditional alloy. Fine-tuned alloy properties for a ride previously impossible without carbon.
SRAM Apex XPLR 12-speed Mechanical
Gravel-specific gearing with 40T / 11-44t range. Apex XPLR rear derailleur, Apex hydraulic disc brakes. Wide range for steep climbs and fast descents.
47c / 650b x 2.1" Tire Clearance
More clearance means more capability. With Diverge-level tire clearance, Crux DSW takes you anywhere you can imagine at full gas.
Performance Gravel Geometry
Longer reach for better weight distribution, lower stack for performance first position. 72mm BB drop hits the sweet spot between nimble and stable. Responsive at the pedals, supple in the saddle.
49 52 54 56 58 61
Crank Length 170 170 172.5 172.5 175 175
Handlebar Width 380 400 420 420 440 440
Stem Length 70 80 90 100 110 110
Saddle Width 155 155 143 143 143 143
Seatpost Length 350 350 350 400 400 400
Stack 530 547 560 578 598 621
Reach 375 382 388 397 405 415
Head Tube Length 100 115 130 147 167 190
Head Tube Angle 70.5° 71.25° 71.5° 72° 72.25° 72.5°
BB Height 284 284 286 286 286 286
BB Drop 74 74 72 72 72 72
Trail 74 69 67 64 62 60
Fork Length, Full 401 401 401 401 401 401
Fork Rake/Offset 50 50 50 50 50 50
Front Center 594 600 608 618 630 644
Chainstay Length 425 425 425 425 425 425
Wheelbase 1008 1014 1023 1033 1045 1059
Top Tube Length, Horizontal 512 539 549 568 582 599
Bike Standover Height 749 772 794 816 841 866
Seat Tube Length 466 496 521 546 576 606
Seat Tube Angle 75.5° 74° 74° 73.5° 73.5° 73.5°
Frameset
Frame
Specialized E5 Premium Aluminum Disc, D'Aluisio Smartweld Technology, hydroformed aluminum tubing, tapered head tube, threaded BB, UDH dropout
Fork
S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc
Seat Binder
Specialized Alloy, 30.8mm
Brakes
Front Brake
SRAM Apex, Hydraulic Disc
Rear Brake
SRAM Apex, Hydraulic Disc
Shift Levers
SRAM Apex, 12-speed
Drivetrain
Bottom Bracket
SRAM DUB BSA 68 Wide
Chain
SRAM Apex D1
Crankset
SRAM Apex XPLR, 40t
Cassette
SRAM PG 1231 XPLR, 11-44t
Rear Derailleur
SRAM Apex XPLR, Mechanical
Wheels & Tires
Front Wheel
DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples
Rear Wheel
DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples
Front Tire
Pathfinder Pro 2BR, 700x38c
Rear Tire
Pathfinder Pro 2BR, 700x38c
Inner Tubes
48mm Presta Valve, 700x28-38
Cockpit
Handlebars
Specialized Adventure Gear, 118.9mm drop x 70mm reach x 12° flare
Stem
Specialized, 3D-forged alloy, 4-bolt, 7-degree rise
Seatpost
Alloy, 2-bolt Clamp, 12mm offset, 27.2mm, anti-corrosion hardware
Saddle
Body Geometry Power Sport, steel rails
Tape
Supacaz Super Sticky Kush

Shipping Policy

Components:

All component items (wheels, drivetrains, suspension, brakes, etc.) ship within 1–4 business days of purchase.

Bicycles:

Complete bikes typically ship within 2–3 weeks due to build, tuning, and inspection times. You will receive tracking information as soon as your order is ready to ship.

Riding Gear & Apparel:

Riding gear and apparel orders (helmets, jerseys, gloves, etc.) ship within 1–3 business days.

Returns & Exchanges:

If you received the wrong size or wish to exchange an item, it must be returned in original condition—unused, uninstalled, and with all packaging intact.

For full details, please see our Refund Policy before initiating a return.

This site is protected by hCaptcha and the hCaptcha Privacy Policy and Terms of Service apply.

Technology
⚙️
D'Aluisio Smartweld (DSW)
Patented hydroforming precisely matches tube-to-tube joints. Lighter, stronger, twice as durable as traditional alloy.
🏆
World's Lightest Alloy Frame
1399g (56cm). No alloy gravel bike can compete. Complete bike just 9.37kg.
🛞
47mm Tire Clearance
Same clearance as carbon Crux. 47mm (700c) or 2.1" (650b). Take anywhere at full gas.
⚡
SRAM Apex XPLR 1x12
Apex 12-speed with XPLR rear derailleur. 40t chainring, 11-44t cassette. Wide range, mechanical shifting.
🎡
DT G540 Wheels
25mm internal width, tubeless ready. Centerlock disc, DT Swiss spokes. Premium alloy gravel wheels.
🌊
S-Works FACT Carbon Fork
Full carbon S-Works fork. 12x100mm thru-axle, flat-mount disc. Race-proven performance.
Built For
Gravel Racing
Cyclocross
All-Road
Fast Fun
Performance Numbers
9.37kg
Bike Weight
Size 56 as built
47mm
Tire Clearance
700c / 2.1" 650b
12
Speeds
Apex XPLR, 11-44t
72mm
BB Drop
Nimble & stable
Gallery
Crux DSW Comp
Crux DSW Comp
Crux DSW Comp
Specifications
Component Detail
FrameE5 Premium Aluminum, D'Aluisio Smartweld, hydroformed tubing, threaded BB
ForkS-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc
ShiftersSRAM Apex, 12-speed
Rear DerailleurSRAM Apex XPLR, mechanical, 12-speed
CranksetSRAM Apex XPLR, 40t
CassetteSRAM PG 1231 XPLR, 11-44t
BrakesSRAM Apex Hydraulic, flat-mount disc
Wheels & Cockpit
DT G540 25mm int / Tubeless Ready
Pathfinder Pro 2BR 700x38c, Tubeless Ready
Specialized Adventure Gear Hover Bars
3D Forged Alloy 4-bolt, 7° Rise
Body Geometry Power Sport Saddle
