2025 Spur Carbon XO AXS
2025 Spur Carbon XO AXS
2025 Spur Carbon XO AXS

2025 Spur Carbon XO AXS

Regular price$8,199.00
/
Shipping calculated at checkout.

Color
Size
  • Free Domestic shipping
  • Low stock - 5 items left
  • Backordered, shipping soon

Key Features

  • Full carbon frame using Japanese Toray fibers with EPS molding and integrated protection
  • 120 mm front and rear travel for balanced XC / trail efficiency
  • FOX 34 Factory FIT4 fork + FLOAT DPS Factory shock with Kashima coating
  • SRAM X0 Eagle Transmission 12-speed AXS wireless drivetrain with Pod Ultimate controller
  • DT Swiss XRC 1501 Carbon wheels with DT 240 hubs and Ratchet EXP freehub
  • SRAM G2 RSC 4-piston brakes with 180 mm HS2 rotors
  • OneUp carbon bar + dropper post (150-210 mm travel by size)
  • Lightweight build — 27 lb 1.5 oz (12.29 kg)
  • Lifetime frame warranty for peace of mind

Full Specifications

Product Transition Spur Carbon X0 AXS Bike
Model Year 2024
Intended Use Cross Country / Trail
Rider Unisex
Wheel Size 29"
Frame Material Carbon Fiber
Frame Material Details Japanese Toray fiber front and rear triangles (24T/30T/40T blend), EPS molding, molded chainstay and down tube protection
Rear Travel 120 mm
Rear Shock FOX FLOAT DPS Factory (3-position lever, Kashima coating, 190 × 45 mm)
Fork FOX FLOAT 34 Factory (FIT4 damper, Kashima coating, 44 mm offset)
Fork Travel 120 mm
Head Tube Diameter Tapered 1 ⅛" – 1 ½"
Headset FSA No.57E (ZS44/ZS56)
Handlebar OneUp Carbon 800 mm (20 mm rise SM/MD, 35 mm LG/XL), 35 mm clamp
Stem ANVL Swage 40 mm length, 35 mm bar clamp
Grips ODI Elite Flow
Brakes SRAM G2 RSC 4-piston brakes with SRAM HS2 180 mm rotors
Brake Levers SRAM G2 RSC tool-free Reach and Contact Point Adjust
Drivetrain 1× SRAM X0 Eagle Transmission 12-speed AXS wireless
Shifters SRAM Eagle Pod Ultimate Controller (AXS wireless)
Front Derailleur None
Rear Derailleur SRAM X0 Eagle Transmission AXS wireless
Cranks SRAM X0 Eagle Transmission Alloy DUB 170 mm
Chainring SRAM X0 Eagle Transmission 32 T
Bottom Bracket SRAM DUB 73 mm BSA threaded
Pedals None
Chain SRAM X0 Eagle Transmission 12-speed
Cassette SRAM X0 Eagle Transmission XS-1295 10-52 T
Rims DT Swiss XRC 1501 Spline 30 Carbon
Hubs DT Swiss 240 (15×110 Boost front / 12×148 Boost rear) with Ratchet EXP XD driver
Spokes DT Swiss Competition Race
Tires Front: Maxxis Dissector 3C MaxxTerra EXO 29 × 2.4"
Rear: Maxxis Rekon 3C MaxxTerra EXO 29 × 2.4"
Saddle ANVL Forge Cromo or SDG Bel-Air 3
Seatpost OneUp Dropper (150 mm SM / 180 mm MD / 210 mm LG-XL)
Seatpost Diameter 31.6 mm
Seatpost Clamp 37.0 mm single-bolt
Rear Dropout / Hub Dimensions 12×148 mm (Boost)
Max Tire Size 29 × 2.4"
Bottle Cage Mounts Inside front triangle, under down tube, and accessory mounts under top tube
Colors Hazy Grey, Blackberry
Warranty Lifetime frame
Weight 27 lb 1.5 oz (12.29 kg) — size MD
Miscellaneous
  • GiddyUp rear suspension design with pivot-less flex-stay triangle
  • Internal cable routing with guide tubes; external rear brake hose
  • SRAM UDH (Universal Derailleur Hanger)
  • Includes SRAM AXS Powerpack charger, tubeless valves, and sealant
  • Rear travel can be reduced to 100 mm with 37.5 mm stroke shock
  • Frame weight (5.4 lb / 2.45 kg) with shock, size MD

Geometry

Size SM MD LG XL
Top Tube Length 569 mm 602 mm 630 mm 664 mm
Head Tube Angle 66° 66° 66° 66°
Head Tube Length 100 mm 110 mm 120 mm 135 mm
Seat Tube Angle 76.7° 76.2° 75.9° 75.6°
Seat Tube Length 380 mm 410 mm 460 mm 500 mm
Bottom Bracket Height 335 mm (40 mm drop) 335 mm (40 mm drop) 335 mm (40 mm drop) 335 mm (40 mm drop)
Chainstay Length 435 mm 435 mm 435 mm 435 mm
Wheelbase 1156 mm 1190 mm 1219 mm 1255 mm
Standover 662 mm 667 mm 670 mm 677 mm
Reach 425 mm 455 mm 480 mm 510 mm
Stack 600 mm 610 mm 619 mm 632 mm
Additional Info
  • Geometry based on 120 mm fork (533 mm axle-to-crown, 44 mm offset)
  • Saddle heights for effective seat tube angle: 600 mm (SM), 660 mm (MD), 720 mm (LG), 780 mm (XL)
  • Seat tube offset at BB: 51 mm (all sizes)
