2025 Specialized STATUS 2 170
- Free Domestic Shipping On Orders Over $100
- Low stock - 8 items left
- Backordered, shipping soon
- Add To Cart For Final Price
STATUS 2 170
Park Bike · 170mm Travel · Gravity Ready
STATUS 2 finds the boundaries of mountain bikes and pushes past them. The 170 build takes it further — more travel, burlier suspension, and gravity-rated tires for riders who push the biggest features and the steepest lines.
- M5 Alloy Chassis: Super strong and durable alloy frame — built for heavy abuse.
- 170mm Travel: Fox Float 38 Rhythm fork + Fox DHX Performance rear shock tuned by Specialized Ride Dynamics.
- Horst Link Flip Chip: Tune geometry to your ride — high or low position.
- Shimano Deore M6100: 12-speed drivetrain with 10-51t cassette — huge range.
- GRID GRAVITY Rear Tire: Butcher GRID GRAVITY casing — burliest tire for park and gravity riding.
- TRP Trail EVO: 4-piston hydraulic discs with 203mm rotors — powerful stoppage.
Whether at the bike park, in the streets, or hitting the biggest jumps — STATUS 2 170 is built for riders who push the limits.
M5 Alloy Chassis
Super strong M5 alloy chassis and rear end — built to withstand heavy abuse from park runs and big jumps.
170mm Fox Suspension
Fox Float 38 Rhythm fork with GRIP damper and two-position Sweep adjustment, 170mm travel. Fox DHX Performance rear shock with Ride Dynamics Trail Tune.
Mixed Wheel Setup
29" front wheel for stability, 27.5" rear wheel for nimble handling. Same as STATUS 2 140.
Horst Link Flip Chip
Flip chips on the Horst pivot link. High position: higher BB, steeper head angle. Low position: 8mm lower BB, half a degree slacker head tube angle.
Butcher GRID GRAVITY
Burliest Butcher casing — GRID GRAVITY on the rear tire is designed for park abuse and gravity riding.
TRP Trail EVO 4-Piston
TRP Trail EVO 4-piston hydraulic disc brakes with 203mm rotors — powerful, consistent stoppage.
| S1 | S2 | S3 | S4 | S5 | |
|---|---|---|---|---|---|
| Crank Length | 165 | 165 | 165 | 165 | 170 |
| Handlebar Width | 780 | 800 | 800 | 800 | 800 |
| Stem Length | 40 | 40 | 40 | 40 | 40 |
| Saddle Width | 143 | 143 | 143 | 143 | 143 |
| Seatpost Length | 125 | 150 | 170 | 170 | 190 |
| Stack (high) | 616 | 620 | 629 | 638 | 647 |
| Stack (low) | 620 | 625 | 634 | 643 | 652 |
| Reach (high) | 426 | 451 | 476 | 501 | 526 |
| Reach (low) | 420 | 445 | 470 | 495 | 520 |
| Head Tube Length | 95 | 100 | 110 | 120 | 130 |
| Head Tube Angle (high) | 64° | 64° | 64° | 64° | 64° |
| Head Tube Angle (low) | 63.5° | 63.5° | 63.5° | 63.5° | 63.5° |
| BB Height (high) | 350 | 350 | 350 | 350 | 350 |
| BB Height (low) | 342 | 342 | 342 | 342 | 342 |
| BB Drop (high) | 26 | 26 | 26 | 26 | 26 |
| BB Drop (low) | 34 | 34 | 34 | 34 | 34 |
| Trail (high) | 133 | 133 | 133 | 133 | 133 |
| Trail (low) | 138 | 138 | 138 | 138 | 138 |
| Fork Length (full) | 581 | 581 | 581 | 581 | 581 |
| Fork Rake/Offset | 44 | 44 | 44 | 44 | 44 |
| Front Center | 762 | 789 | 819 | 848 | 878 |
| Chainstay Length (high) | 428 | 428 | 428 | 433 | 433 |
| Chainstay Length (low) | 432 | 432 | 432 | 437 | 437 |
| Wheelbase | 1193 | 1221 | 1250 | 1285 | 1314 |
| Top Tube Length (horizontal) | 554 | 595 | 635 | 676 | 716 |
| Bike Stand Over Height | 735 | 735 | 742 | 748 | 752 |
| Seat Tube Length | 390 | 400 | 420 | 440 | 465 |
| Seat Tube Angle (high) | 77.6° | 77.6° | 77.6° | 77.6° | 77.6° |
| Seat Tube Angle (low) | 77° | 77° | 77° | 77° | 77° |
Frameset
Frame
M5 Alloy chassis and rear-end, Trail Geometry, Horst pivot geo adjustment, threaded BB, internal cable routing with external rear brake option, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 170mm travel
Seat Binder
Alloy, 38.6mm
Suspension
Fork
Fox Float 38 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset, 170mm travel
Rear Shock
Fox DHX Performance, Ride Dynamics Trail Tune. S1: 230x60mm (350lbs), S2: 230x62.5mm (400lbs), S3: 230x62.5mm (450lbs), S4: 230x62.5mm (500lbs), S5: 230x62.5mm (550lbs)
Brakes
Front Brake
TRP Trail EVO, 4-piston caliper, hydraulic disc, 203mm
Rear Brake
TRP Trail EVO, 4-piston caliper, hydraulic disc, 203mm
Drivetrain
Chainrings
Shimano Deore M6120, 32T ring, 55mm chainline
Crankset
Shimano Deore M6120, S1-S4: 165mm, S5: 170mm
Chain
Shimano Deore M6100, 12-speed
Shift Levers
Shimano Deore M6100, I-Spec EV, 12 speed
Rear Derailleur
Shimano Deore M6100, 12-speed, Shadow Plus
Cassette
Shimano Deore M6100, 12-speed w/ Hyperglide+, 10-51t
Wheels & Tires
Rims
Specialized hookless alloy, 30mm inner width, tubeless ready
Spokes
DT Swiss Industry
Front Tire
Butcher, GRID TRAIL casing, GRIPTON T9 compound, 2Bliss Ready, 29x2.3"
Rear Tire
Butcher, GRID GRAVITY casing, GRIPTON T9 compound, 2Bliss Ready, 27.5x2.3"
Front Hub
Sealed cartridge bearings, 6-bolt, 15x110mm thru-axle, 32h
Rear Hub
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
Inner Tubes
Standard, Presta valve
Cockpit
Stem
Alloy Trail Stem, 35mm bar bore
Handlebars
Specialized 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise. S1: 780mm width, S2-S5: 800mm width
Seatpost
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9mm. S1: 125mm, S2: 150mm, S3-S4: 170mm, S5: 190mm
Saddle
Bridge Comp, Hollow Cr-mo rails, 143mm
Grips
Deity Knuckleduster
Weight
Weight
17.28kg (38 lb, 1.5 oz)
Weight Size
S3
