Name: 2026 Orbea Rise LT M20 E-Bike
Brand: Orbea
Price: 7199.0 USD
Availability: InStock

$7,199.00

Shipping calculated at checkout.

Free Domestic shipping

Low stock - 2 items left
Backordered, shipping soon

Key Features

Orbea Rise LT OMR Carbon frame (2025) with 150mm of travel and adjustable geometry via flip-chip.
Custom-tuned Shimano EP801 RS Gen2 MC motor paired with a lightweight Orbea Internal 420Wh battery.
Performance suspension featuring the Fox 36 Float Performance fork (160mm, Grip 3-Pos) and Fox Float Performance rear shock.
Reliable Shimano SLX 1x12-speed drivetrain for trail-ready shifting performance.
Powerful Shimano M6120 4-piston Hydraulic Disc Brakes with large 203mm front rotor.
Durable Race Face AR 30c Tubeless Ready wheelset.
Aggressive Maxxis tire combination: Assegai (front, MaxxGrip) and Minion DHR II (rear, MaxxTerra Exo+).
Integrated minimalist control system using the EN600-L Remote.
Features 160mm of front travel which slackens the geometry for increased downhill capability.

Full Specifications

Frame	Orbea Rise LT OMR 2025 Carbon, 150mm travel, 29" wheels, Concentric Boost 12x148
Rear Shock	Fox Float Performance 2-Pos Evol LV custom tune 210x55mm
Fork	Fox 36 Float Performance 160, Grip 3-Pos, QR15x110
Fork Travel	160mm
Head Tube Diameter	1-1/2" (Steerer tube: Alloy, Black Oxidated Bearing)
Motor	Shimano EP801 RS Gen2 MC (Rider Synergy motor)
Battery	Orbea Internal 420Wh
Charger	Orbea 2.Generation eBike Smart charger 42V/2-4A
Remote	EN600-L
Chainring	ethirteen Helix Core espec Direct Mount 32T, 55mm ChainLine
Cranks	Shimano Steps EM600
Shifters	Shimano SLX M7100 I-Spec EV, 12-speed
Cassette	Shimano CS-M7100 (SLX), 10-51t, 12-Speed
Rear Derailleur	Shimano SLX M7100 SGS Shadow Plus, 12s
Chain	Shimano M6100 (Deore)
Chainguide	Orbea eBike chainguide
Handlebar	OC Mountain Control MC31, Rise 20, Width 800mm
Stem	OC Mountain Control MC20, 0º
Computer Mount	OC Computer Mount CM-05, Garmin/Sigma
Brakes	Shimano M6120 Hydraulic Disc (4-piston)
Rotors	Shimano RT64 Rotors, 203mm front / 180mm rear
Wheels	Race Face AR 30c Tubeless Ready
Front Tire	Maxxis Assegai 2.50", 60TPI, 3CG/EXO+/TR, MaxxGrip
Rear Tire	Maxxis Minion DHR II 2.40" WT FB, 120 TPI, 3C MaxxTerra Exo+ TR
Seatpost	OC Mountain Control MC22, 31.6mm, Dropper
Seatpost Lever	Shimano SL-MT500 I-Spec EV
Saddle	Fizik Terra Ridon X5 145mm
Grips	OC Lock On
Tools / Accessories	N/A

Geometry

Size (Setting)	SM (High, Low)	MD (High, Low)	LG (High, Low)	XL (High, Low)
Top Tube Length	569mm, 570mm	595mm, 614mm	622mm, 620mm	637mm, 647mm
Head Tube Angle	64.5°, 64.0°	64.5°, 64.0°	64.5°, 64.0°	64.5°, 64.0°
Head Tube Length	95mm	100mm	110mm	120mm
Seat Tube Angle	77.5°, 77.0°	77.5°, 77.0°	77.5°, 77.0°	77.5°, 77.0°
Seat Tube Length	405mm	415mm	430mm	460mm
Bottom Bracket Height	Drop: 26mm, 34mm	Drop: 26mm, 34mm	Drop: 26mm, 34mm	Drop: 26mm, 34mm
Chainstay Length	440mm	440mm	440mm	440mm
Wheelbase	1201mm, 1203mm	1228mm, 1230mm	1258mm, 1259mm	1287mm, 1288mm
Reach	435mm, 430mm	460mm, 455mm	485mm, 480mm	510mm, 505mm
Stack	614mm, 619mm	617mm, 623mm	623mm, 633mm	637mm, 642mm
Additional Info	Geometry figures are provided for the High and Low flip-chip settings. The Low setting provides a slacker head angle (64.0°) and lower bottom bracket (34mm drop) for gravity riding. The High setting steepens the angles (64.5° HTA) for better climbing and general trail use.
