Name: 2026 Orbea Rise LT M10 E-Bike
Brand: Orbea
Price: 8599.0 USD
Availability: InStock

$8,599.00

Shipping calculated at checkout.

Free Domestic shipping

Low stock - 2 items left
Backordered, shipping soon

Key Features

Orbea Rise LT OMR Carbon frame (2025) providing 150mm of lightweight trail/enduro travel.
Custom-tuned Shimano EP801 RS Gen2 MC motor paired with a lightweight Orbea Internal 420Wh battery.
Top-tier FOX Factory Suspension: Features the 36 Float Fork (160mm, Grip X, Kashima) and Float X Factory air shock (Kashima).
High-performance Shimano XT M8200 12-speed drivetrain for precise and reliable shifting.
Powerful Shimano XT 8220 4-piston Hydraulic Disc Brakes with a 203mm front rotor for maximum stopping control.
High-quality Oquo Mountain Control MC32TEAM wheelset.
Aggressive Maxxis tire combination: Assegai (front, MaxxGrip) and Minion DHR II (rear, MaxxTerra Exo+).
Integrated cockpit controls including an OC Mountain Control Carbon handlebar and Electronic Dropper post.
Includes the useful OC FLP Multitool MT-20 concealed in the bike.

Full Specifications

Frame	Orbea Rise LT OMR 2025 Carbon, 150mm travel, 29" wheels, Concentric Boost 12x148
Rear Shock	Fox Float X Factory 2-Pos Adjust Evol LV Kashima custom tune 210x55mm
Fork	Fox 36 Float Factory 160, Grip X damper, QR15x110, Kashima coating
Fork Travel	160mm
Head Tube Diameter	1-1/2" (Steerer tube: Alloy, Black Oxidated Bearing)
Motor	Shimano EP801 RS Gen2 MC (Rider Synergy motor)
Battery	Orbea Internal 420Wh
Charger	Orbea 2.Generation eBike Smart charger 42V/2-4A
Remote	Orbea System Controller with eDropper Remote
Chainring	ethirteen Helix Core espec Direct Mount 32T, 55mm ChainLine
Cranks	Shimano Steps EM600
Shifters	Shimano XT M8250, 12-speed
Cassette	Shimano CS-M7100 (SLX), 10-51t, 12-Speed
Rear Derailleur	Shimano XT M8260 SGS, 12s
Chain	Shimano M7100 (SLX)
Chainguide	Orbea eBike chainguide
Handlebar	OC Mountain Control MC10 Carbon, Rise 20, Width 800mm
Stem	OC Mountain Control MC20, 0º
Computer Mount	OC Computer Mount CM-05, Garmin/Sigma
Brakes	Shimano XT 8220 Hydraulic Disc (4-piston)
Rotors	Galfer Wave Rotors, 203mm front / 180mm rear
Wheels	Oquo Mountain Control MC32TEAM
Front Tire	Maxxis Assegai 2.50", 60TPI, 3CG/EXO+/TR, MaxxGrip
Rear Tire	Maxxis Minion DHR II 2.40" WT FB, 120 TPI, 3C MaxxTerra Exo+ TR
Seatpost	OC Mountain Control MC10, 31.6mm, Electronic Dropper
Saddle	Fizik Terra Ridon X5 145mm
Tools / Accessories	OC FLP Multitool MT-20 (Hex 2, 3, 4, 5) + OC Rear axle lever (Hex 6 & valve core removal)

Geometry

Size	SM	MD	LG	XL
Top Tube Length	610mm	614mm	620mm	647mm
Head Tube Angle	65.5°	65.5°	65.5°	65.5°
Head Tube Length	95mm	100mm	110mm	120mm
Seat Tube Angle	78°	78°	78°	78°
Seat Tube Length	405mm	415mm	430mm	460mm
Bottom Bracket Height	37mm drop	37mm drop	37mm drop	37mm drop
Chainstay Length	440mm	440mm	440mm	440mm
Wheelbase	1193mm	1220mm	1249mm	1279mm
Reach	440mm	465mm	490mm	515mm
Stack	609mm	614mm	623mm	632mm
Additional Info	Note: The geometry figures listed were calculated with a 140mm travel fork. Since this bike is equipped with a 160mm fork, the actual head tube angle will be slacker (less than 65.5°) and the stack/reach will be slightly different than listed in this table, resulting in a more aggressive, gravity-focused stance.
