Name: 2026 Orbea Occam SL H30 Bike
Brand: Orbea
Price: 2698.0 USD
Availability: InStock

$2,999.00 $2,698.00 Save $301.00

Shipping calculated at checkout.

Free Domestic shipping

Low stock - 2 items left
Backordered, shipping soon

Key Features

Orbea Occam Hydro aluminum frame, featuring Asymmetric design and Concentric Boost rear axle.
Capable suspension handled by the Marzocchi Bomber Z2 140 fork and Fox Float Performance shock.
Integrated OC Squidlock MC20 Remote controls suspension lockout and dropper post from a single lever.
Reliable Shimano Deore 1x12-speed drivetrain with a wide-range 10-51t cassette.
Confident stopping power from Shimano MT201 Hydraulic Disc Brakes.
Durable Alloy, 29c, Tubeless Ready wheelset.
Aggressive Maxxis tire pairing: Dissector (front) and Rekon (rear) for a balance of grip and rolling speed.
Features the Pure Trail geometry with a slack 65.5° head tube angle.
Frame supports internal cable routing and includes Accessories Containers for storage.

Full Specifications

Frame	Orbea Occam Hydro, Concentric Boost 12x148 rear axle, Pure Trail geometry, Asymmetric design, 29" wheels, Linkage compatible with OC multitool
Rear Shock	Fox Float Performance Remote Push-lock Evol custom tune 210x50mm
Rear Travel	140mm (Assumed, based on fork/geometry context)
Fork	Marzocchi Bomber Z2 140 Rail Remote Push-Lock QR15x110
Fork Travel	140mm
Remote Lockout	OC Squidlock MC20 Remote, Dropper, Suspension 2 Pos
Head Tube Diameter	1-1/2" (Steerer tube: FSA 1-1/2" Integrated Aluminium Cup)
Handlebar	OC Mountain Control MC30, Rise 20, 800mm Width
Stem	OC Mountain Control MC20, 0º
Grips	OC Lock On
Brakes	Shimano MT201 Hydraulic Disc
Rotors	(Not specified, typically 160mm/180mm)
Drivetrain	1x
Shifters	Shimano Deore M6100, 12-speed
Rear Derailleur	Shimano Deore M6100 SGS Shadow Plus, 12-Speed
Crankset	Forged alloy, 32 tooth
Bottom Bracket	(Not specified by type)
Chain	Shimano M6100 (Deore), 12-speed
Cassette	Shimano CS-M6100 (Deore), 10-51t, 12-Speed
Wheels	Alloy, Tubeless, 29", 29c inner width, 32H
Front Tire	Maxxis Dissector 2.40" 60TPI Rigid EXO/TR
Rear Tire	Maxxis Rekon 2.4" 60 TPI Rigid EXO/TR
Saddle	Selle Royal 2058 DRN
Seatpost	OC Mountain Control MC22, 31.6mm, Dropper
Seatpost Lever	(Integrated into OC Squidlock MC20 remote)
Rear Dropout / Hub Dimensions	12mm x 148mm (Boost)
Miscellaneous	Internal/External Cable Routing options, Accessories Containers for storage

Geometry

Size	SM	MD	LG	XL
Seat Tube (C-T)	405mm	415mm	430mm	460mm
Top Tube (EFF)	570mm	595mm	622mm	650mm
Head Tube	95mm	100mm	110mm	120mm
Chainstay	439mm	439mm	439mm	439mm
BB Drop	38mm	38mm	38mm	38mm
BB Height	342mm	342mm	342mm	342mm
Wheelbase	1191mm	1218mm	1245mm	1276mm
Head Angle	65.5°	65.5°	65.5°	65.5°
Seat Angle	78°	78°	78°	78°
Rake	44mm	44mm	44mm	44mm
Reach	440mm	465mm	490mm	515mm
Stack	610mm	615mm	623mm	633mm
Fork Length	554mm	554mm	554mm	554mm
