Yeti Cycles

SB160, 2023

Regular price$9,132.39
/
Shipping calculated at checkout.
Kit
Color
Size
  • Low stock - 1 item left
  • Inventory on the way

 Please Visit Yeti for Full Spec Sheets!

https://yeticycles.com/bikes/sb160

UPHOLDING A TIME-TESTED, RACE-BRED ETHOS THAT SAYS NOTHING SHOULD HOLD A RIDER BACK FROM THE SHEER JOY OF UNTETHERED SPEED. BUILT OFF ONE OF THE MOST WINNING RACE PLATFORMS IN EWS HISTORY, THE SB160 IS PURE RACE MACHINERY. HONED FOR MORE.
BE FASTEST.

SWITCH INFINTY. RECALCULATED.

Discover the next-generation of translating pivot suspension designs. Setting new expectations for kinematics, longevity, sensitivity, and strength.

THE NEW SILHOUETTE OF SPEED.

The refined main frame and swingarm silhouette is more than just striking good looks — it’s an engineering approach that packages Switch Infinity and shock linkage in a tighter, more efficient frame with added impact clearance. Holistic frame chassis stiffness has increased, along with frame ground clearance.

UNPARALLELED FEEL.
FOR ALL RIDERS.

Every rider deserves a frame feel that’s tuned for them, regardless of frame size. Over the course of hundreds of virtual simulation comparisons and back-to-back carbon prototype testing, we’ve refined our carbon layups to deliver consistent torsional stiffness and flex profiles across all frame sizes. The feel is precise yet compliant while structurally balancing lightweight and durability.

PATENTED COMPACT WISHBONE.

Our patented, two-piece wishbone shock extender on the SB160 ensures optimal clamping, shock compatibility, and ease of shock removal for longer travel applications.

We are able to optimize leverage rates while pushing the shock forward in the frame. This forward positioning allows for a large range of shock compatibility, decreases standover height, reduces shock tab sizes, increases water bottle compatibility, and increases downtube clearance.

LEVERAGE RATE FOR REAL SPEED.

Forget what you know — the clock proves more progressive curves aren’t faster. The SB160’s kinematics have been refined for the added travel with increased bottom out control while maintaining a relatively linear progression curve. Why a linear curve? Athletes experience more predictable damping characteristics throughout the travel. Predictability in a competition setting can make the difference between participating or winning.

MORE BALANCED AT SPEED.

Our factory team wanted even more confidence at pace. To achieve this, we’ve further refined geometry with little more reach, rebalanced front and rear centers, and size-specific chainstay and seat tube angles. It’s our most confidence inspiring geo to date. And it’s optimized by frame size, ensuring athletes of all sizes and styles are in a position that prioritizes speed and efficiency.

T4

T4

$10,800

T3 X0 TRANSMISSION

$9,800

T3

$9,100

T1

$8,500

C2

$7,000

C1

$6,700

FRAME ONLY

$5,000
DETAILS T4, TURQ series carbon, SRAM XX1 Eagle AXS, Fox Factory 38 GRIP2 Fork T3 X0 Transmission, TURQ series carbon, SRAM X0 Eagle AXS Transmission, Fox Factory 38 GRIP2 Fork T3, TURQ series carbon, SRAM XX1 Eagle AXS, Fox Factory 38 GRIP2 Fork T1, TURQ series carbon, SRAM X01 Eagle, Fox Factory 38 GRIP2 Fork C2, C series carbon, SRAM GX Eagle, Fox Performance 38 Fork C1, C series carbon, Shimano SLX, Fox Performance 38 Fork TURQ series carbon
FRAME TURQ Series carbon fiber frame, Switch Infinity V2 suspension technology, Threaded BB, internally tunneled cable routing, 148mm x 12mm BOOST dropouts, sealed enduro max pivot bearings, Universal derailleur hanger (UDH), and axle. TURQ Series carbon fiber frame, Switch Infinity V2 suspension technology, Threaded BB, internally tunneled cable routing, 148mm x 12mm BOOST dropouts, sealed enduro max pivot bearings, Universal derailleur hanger (UDH), and axle. TURQ Series carbon fiber frame, Switch Infinity V2 suspension technology, Threaded BB, internally tunneled cable routing, 148mm x 12mm BOOST dropouts, sealed enduro max pivot bearings, Universal derailleur hanger (UDH), and axle. TURQ Series carbon fiber frame, Switch Infinity V2 suspension technology, Threaded BB, internally tunneled cable routing, 148mm x 12mm BOOST dropouts, sealed enduro max pivot bearings, Universal derailleur hanger (UDH), and axle. C/Series carbon fiber frame, Switch Infinity suspension technology, Threaded BB, internally tunneled cable routing, 148mm x 12mm BOOST dropouts, sealed enduro max pivot bearings, Universal derailleur hanger (UDH), and axle. C/Series carbon fiber frame, Switch Infinity suspension technology, Threaded BB, internally tunneled cable routing, 148mm x 12mm BOOST dropouts, sealed enduro max pivot bearings, Universal derailleur hanger (UDH), and axle. TURQ Series carbon fiber frame, Switch Infinity V2 suspension technology, Threaded BB, internally tunneled cable routing, 148mm x 12mm BOOST dropouts, sealed enduro max pivot bearings, Universal derailleur hanger (UDH), and axle.
FORK FOX FACTORY 38 GRIP 2/170MM FOX FACTORY 38 GRIP 2/170MM FOX FACTORY 38 GRIP 2/170MM FOX FACTORY 38 GRIP 2/170MM FOX PERFORMANCE 38/170MMUPGRADABLE FOX PERFORMANCE 38/170MMUPGRADABLE
MATERIAL TURQ SERIES T/SERIES TURQ SERIES TURQ SERIES C/SERIES C/SERIES TURQ SERIES
WEIGHT 33.10 33.89 33.30 33.2 34.04 34.09 8.39
TRAVEL 160MM (6.3") 160MM (6.3") 160MM (6.3") 160MM (6.3") 160MM (6.3") 160MM (6.3") 160MM (6.3")
REAR SHOCK FOX FACTORY FLOAT X2 FOX FACTORY FLOAT X2 FOX FACTORY FLOAT X2 FOX FACTORY FLOAT X2 FOX PERFORMANCE FLOAT XUPGRADABLE FOX PERFORMANCE FLOAT XUPGRADABLE FOX FACTORY FLOAT X2
WHEELSET DT SWISS CUSTOM EX1700 30MMUPGRADABLE DT SWISS CUSTOM EX1700 30MMUPGRADABLE DT SWISS CUSTOM EX1700 30MMUPGRADABLE DT SWISS CUSTOM EX1700 30MMUPGRADABLE DT SWISS E1900 30MM DT SWISS E1900 30MM
REAR DER SRAM XX1 EAGLE AXS SRAM X0 EAGLE AXS TRANSMISSION SRAM XX1 EAGLE AXS SRAM X01 EAGLE SRAM GX EAGLE SHIMANO SLX
SHIFT SRAM EAGLE AXS SRAM AXS POD CONTROLLER SRAM EAGLE AXS SRAM GX EAGLE SRAM GX EAGLE SHIMANO XT
CRANK SRAM X01 EAGLE 30T 170MM SRAM X0 EAGLE TRANSMISSION 30T 170MM SRAM X1 CARBON EAGLE 30T 170MM SRAM X1 CARBON EAGLE 30T 170MM SRAM GX EAGLE 30T 170MM SHIMANO SLX 30T 170MM
BB SRAM DUB BSA 73 SRAM DUB BSA 73 SRAM DUB BSA 73 SRAM DUB BSA 73 SRAM DUB BSA 73 SHIMANO XT BB 73
CASSETTE SRAM XX1 EAGLE 1299 10-52 SRAM X0 EAGLE TRANSMISSION 10-52 SRAM X01 EAGLE 1295 10-52 SRAM GX EAGLE 1275 10-52 SRAM GX EAGLE 1275 10-52 SHIMANO SLX 10-51
CHAIN SRAM XX1 EAGLE SRAM X0 EAGLE TRANSMISSION FLATTOP SRAM GX EAGLE SRAM GX EAGLE SRAM GX EAGLE SHIMANO SLX
BRAKES SRAM CODE RSC SRAM CODE RSC SRAM CODE RSC SRAM CODE RSC SRAM CODE R SHIMANO SLX 4 PISTON
ROTORS SRAM CENTERLINE 220/SRAM CENTERLINE 200 SRAM CENTERLINE 220/SRAM CENTERLINE 200 SRAM CENTERLINE 220/SRAM CENTERLINE 200 SRAM CENTERLINE 220/SRAM CENTERLINE 200 SRAM CENTERLINE 220/SRAM CENTERLINE 200 SHIMANO 220/SHIMANO 203
POST FOX TRANSFER FACTORY 31.6MM / SM: 150MM, MD: 175MM, LG-XXL: 200MM FOX TRANSFER 31.6MM / SM: 150MM, MD: 175MM, LG-XXL: 200MM FOX TRANSFER 31.6MM / SM: 150MM, MD: 175MM, LG-XXL: 200MM FOX TRANSFER 31.6MM / SM: 150MM, MD: 175MM, LG-XXL: 200MM ONEUP DROPPER POST 31.6MM / SM: 150MM, MD: 180MM, LG-XXL: 210MM ONEUP DROPPER POST 31.6MM / SM: 150MM, MD: 180MM, LG-XXL: 210MM
FRONT TIRE MAXXIS ASSEGAI 2.5 EXO+ MAXXIS ASSEGAI 2.5 EXO+ MAXXIS ASSEGAI 2.5 EXO+ MAXXIS ASSEGAI 2.5 EXO+ MAXXIS ASSEGAI 2.5 EXO+ MAXXIS ASSEGAI 2.5 EXO+
REAR TIRE MAXXIS MINION DHR II 2.4 EXO+ MAXXIS MINION DHR II 2.4 EXO+ MAXXIS MINION DHR II 2.4 EXO+ MAXXIS MINION DHR II 2.4 EXO+ MAXXIS MINION DHR II 2.4 EXO+ MAXXIS MINION DHR II 2.4 EXO+
HEADSET CANE CREEK 110 INTEGRATED CANE CREEK 40 INTEGRATED CANE CREEK 40 INTEGRATED CANE CREEK 40 INTEGRATED CANE CREEK 40 INTEGRATED CANE CREEK 40 INTEGRATED
BAR YETI CARBON 35X800MM YETI CARBON 35X800MM YETI CARBON 35X800MM YETI CARBON 35X800MM BURGTEC RIDE WIDE ALLOY ENDURO 35X800MM 35MM RISE BURGTEC RIDE WIDE ALLOY ENDURO 35X800MM 35MM RISE
STEM BURGTEC ENDURO MK3 CNC 35X50MM BURGTEC ENDURO MK3 35X50MM BURGTEC ENDURO MK3 35X50MM BURGTEC ENDURO MK3 35X50MM BURGTEC ENDURO MK3 35X50MM BURGTEC ENDURO MK3 35X50MM
GRIPS ODI ELITE PRO ODI ELITE PRO ODI ELITE PRO ODI ELITE PRO ODI ELITE PRO ODI ELITE PRO
SEAT ERGON SM ENDURO SADDLE SILVERADO CUSTOM SILVERADO CUSTOM SILVERADO CUSTOM SILVERADO CUSTOM SILVERADO CUSTOM
$10,800

T3 X0 TRANSMISSION

$9,800

T3

$9,100

T1

$8,500

C2

$7,000

C1

$6,700

FRAME ONLY

$5,000
